The AD100 series Ultra Dog latch is designed for commercial, outswing doors. The Ultra Dog Door Security Bar opens at the push of the bar FROM THE INSIDE. Includes installation instructions, attachment blocks, hardware, storage hanger kit and door label.
In order to determine what unit to order, you'll need the following dimensions:
* Frame Opening Width (defines bar lengths)
* Face-to-Face dimension (the distance from the face of the door to the face of the jamb).
You'll also need to select the correct Jamb Kit for the larger jamb sizes. The perfect commercial door security latch. Visit us at our website and YouTube for the How to Measure for Ultra Dog video.
|General description||: Ultra-Dog for a 48" single, commercial|
|Weight||: 12.4 lbs, ships via UPS|
|Warranty||: Five (5) years from original purchase|
|Main support pieces, rods, storage hook|
|and mounting brackets||: Steel|
|Block and handle supports||: High impact plastic|
|Rod cushions||: Rubber|
|Dia||: 1" Round|
|Inside length||: 38-3/8"|
|Support bar (connects handle, locking rods and blocks)|
|Tubing size||: 1" square|
|Length between blocks||: 47-1/2"|
|Length, from face of support bar to inside of 90o bend||: 6"|
|Height of hook||: 1-5/8"|
|Hook to hook OC||: 39-5/8"|
|There is a rubber tip on the end of each hook|
|Outside dia||: 1/2"|
|Thickness of rubber||: 3/64"|
|Height, at highest point||: 4-9/16"|
|There is a bolt that runs through the center of each block,|
|which is used to shorten and lengthen the distance from|
|the front face of the block from the main support bar,|
|allowing the Ultra-Dot to fit a range of mullion depths.|
|Holding brackets - triangular shape, mount to the face of the door|
|Qty provided||: 2 each|
|Material thickness||: 1/8"|
|Height of back portion||: 2-3/4"|
|Inside width||: 1"|
|Inside depth||: 1-1/16"|
|Dia of holding rod||: 3/8"|
|Hole to hole OC||: 1-7/8"|
|Material thickness||: 5/64"|
|Outside height||: 2-1/32"|
|Inside depth||: 1/2"|
|Dia||: 13/64" (between 3/16" and 7/32")|
|Hole to hole OC||: 1/2"|
|Mounting hardware (included)|
|- 4 Each 5/16-18 x 2-1/4" Large head carriage bolt|
|- 4 Each 5/16-18 Hex nut with 1/2" drive|
|- 4 Each Flat washers, 7/8" OD, 13/32" ID, 3/32" thick|
|- 2 Each #10 x 3/4" Hex washer head thread forming screw|
|with 5/16" drive|
|- 2 Each Self adhesive felt pads for the end of the block|
|3/4" wide x 4" long x 1/32" thick, black|
|- 'Ultra-Dog Protected' self-adhesive sign, 2-3/8" x 3-1/4" Oval|
|- Installation instructions and adjustment procedures,|
|in English, Spanish and French|
